Public API

ConduitGrpcSdk

class ConduitGrpcSdk {
  constructor(
    serverUrl: string,
    fetchModules: () => Promise<any>,
    watchModules: boolean,
    serviceUrl?: string,
    metrics?: IConduitMetrics,
    logger?: IConduitLogger,
  );
  readonly name: string;
  readonly instance: string;
  // Module accessors (lazily resolved):
  get authentication(): Authentication | undefined;
  get database(): DatabaseProvider | undefined;
  get storage(): Storage | undefined;
  get email(): Email | undefined;
  get router(): Router | undefined;
  get config(): Config | undefined;
  get core(): Core | undefined;
}

The central SDK class. Instantiate it once per service, passing the Core gRPC address and a function that returns the current module list. Use module accessors to obtain typed gRPC clients for each Conduit subsystem once they become available.

ConduitModule

abstract class ConduitModule<T extends CompatServiceDefinition> {
  // Base class for all typed module wrappers.
  // Provides connection lifecycle, health-check integration,
  // and a typed nice-grpc Client<T>.
}

Extend this class when writing a custom Conduit module client. It handles gRPC channel setup, retry logic, and exposes the underlying Client<T> from nice-grpc.

GrpcError

class GrpcError extends Error {
  constructor(code: status, message: string);
  readonly code: status; // @grpc/grpc-js status code
}

Throw GrpcError inside any gRPC handler to return a well-formed gRPC status to the caller. Use the status enum from @grpc/grpc-js (e.g. status.NOT_FOUND, status.INVALID_ARGUMENT).

checkModuleHealth

function checkModuleHealth(
  client: Client<typeof HealthDefinition>,
  moduleName: string,
): Promise<HealthCheckStatus>;

Pings a module's gRPC health endpoint and resolves with its current HealthCheckStatus. Use this in readiness probes or before attempting to call a module that may not yet be registered with Core.

Working examples

Scenario - Initialising the SDK and accessing the Database module

A custom Conduit module needs to read and write data via the Database module client.

import ConduitGrpcSdk from './vendor/grpc-sdk/src/index.js';

const sdk = new ConduitGrpcSdk(
  process.env.CONDUIT_SERVER!,
  async () => [], // replace with real module-fetch logic
  true,
  process.env.SERVICE_URL,
);

async function main() {
  // Wait until the database module is registered and healthy
  await sdk.waitForExistence('database');
  const db = sdk.database!;
  console.log('Database module ready:', db);
}

main().catch(console.error);

Scenario - Throwing a typed gRPC error in a handler

A gRPC service handler must reject an invalid request with a proper status code.

import { GrpcError } from './vendor/grpc-sdk/src/classes/index.js';
import { status } from '@grpc/grpc-js';

async function getUser(call: any) {
  const { id } = call.request;
  if (!id) {
    throw new GrpcError(status.INVALID_ARGUMENT, 'User ID is required');
  }
  // ... fetch user logic
}

Scenario - Checking module health before calling it

Before sending emails, verify the Email module is serving.

import { checkModuleHealth } from './vendor/grpc-sdk/src/classes/index.js';
import { HealthCheckStatus } from './vendor/grpc-sdk/src/types/index.js';
import { Client } from 'nice-grpc';
import { HealthDefinition } from './vendor/grpc-sdk/src/protoUtils/index.js';

async function ensureEmailReady(
  healthClient: Client<typeof HealthDefinition>,
): Promise<void> {
  const result = await checkModuleHealth(healthClient, 'email');
  if (result !== HealthCheckStatus.SERVING) {
    throw new Error(`Email module not ready: ${result}`);
  }
  console.log('Email module is healthy');
}

Scenario - Using EventBus and StateManager for inter-module events

Publish a domain event after a user action and react to it in another handler.

import { EventBus, StateManager, RedisManager } from './vendor/grpc-sdk/src/utilities/index.js';

async function setupBus(redisHost: string, redisPort: number) {
  const redisManager = new RedisManager({ host: redisHost, port: redisPort });
  const bus = new EventBus(redisManager);
  const state = new StateManager(redisManager, 'my-module');

  bus.subscribe('user.registered', async (data: string) => {
    const parsed = JSON.parse(data);
    await state.setState('lastRegistered', parsed.userId);
    console.log('Stored last registered user:', parsed.userId);
  });

  bus.publish('user.registered', JSON.stringify({ userId: 'abc123' }));
}

setupBus(process.env.REDIS_HOST!, Number(process.env.REDIS_PORT!));

File walkthrough

• .github/ - GitHub Actions CI pipelines for every Conduit module plus release workflows; not needed at runtime.
• deploy/ - Production-grade Docker Compose and Helm/Kubernetes values files for full Conduit stack deployment.
• docker/ - Local development Compose files; includes Prometheus and Loki config for observability.
• libraries/grpc-sdk/ - The primary artifact of this block: the SDK consumed by all modules and custom integrations.
• libraries/hermes/ - HTTP/WebSocket transport abstraction used by the Router module.
• libraries/module-tools/ - Shared build and scaffolding utilities for Conduit modules.
• libraries/node-2fa/ - TOTP/HOTP two-factor authentication helper library.
• libraries/testing-tools/ - Test harness utilities for Conduit module integration tests.
• modules/ - Source for all official Conduit modules (authentication, chat, database, email, etc.).
• packages/ - Internal shared TypeScript packages (proto-generated types, common interfaces).
• scripts/ - Release, versioning, and repository maintenance automation.
• standalone/ - Single-process entry point that boots all modules together without Kubernetes.
• lerna.json - Defines the monorepo package versioning and publish strategy.
• turbo.json - Turborepo pipeline that orchestrates build/test/lint across all packages.
• package.json - Root workspace definition; lists all workspace globs.
• standalone.Dockerfile - Multi-stage Docker image for the all-in-one standalone deployment.

Common pitfalls and fixes

• ESM .js extension errors: The SDK uses import ... from './foo.js' throughout; if TypeScript complains, set "moduleResolution": "NodeNext" and "module": "NodeNext" in tsconfig.json.
• CONDUIT_SERVER not set: ConduitGrpcSdk will throw immediately at construction; always validate env vars before instantiation.
• Redis connection refused: RedisManager, EventBus, and StateManager all require a live Redis instance; ensure Redis is started before your service and that REDIS_HOST/REDIS_PORT are correct.
• Module accessor returns undefined: Module clients are only available after the module is registered with Core; use sdk.waitForExistence('<moduleName>') before accessing any module property.
• fast-jwt createSigner version mismatch: The SDK calls createSigner from fast-jwt; pin to fast-jwt@^2 to match the SDK's expected API surface.
• Proto-generated files missing: If you move grpc-sdk without running its build (cd libraries/grpc-sdk && sh build.sh), the protoUtils/ imports will be absent; run the build step after copying.

Vibe-coding prompt template

I have copied the Conduit gRPC SDK source into `src/vendor/grpc-sdk` in my
Node.js TypeScript project. The upstream package is `user@example.com`.
There is a USAGE.md at the root of this block that describes all real exports,
environment variables, and working code snippets.

Please help me integrate this SDK step by step:

1. Read USAGE.md and src/vendor/grpc-sdk/src/index.ts to understand all
   available exports.
2. Update my tsconfig.json for NodeNext module resolution and add a path alias
   for `@grpc-sdk/*` pointing to `src/vendor/grpc-sdk/src/*`.
3. Create a `src/sdk.ts` singleton that instantiates ConduitGrpcSdk using
   environment variables CONDUIT_SERVER and SERVICE_URL.
4. In my Express app's startup function, wait for the `database` module to
   become available and log confirmation.
5. Add a gRPC error handler that catches GrpcError and maps it to an HTTP
   status response.
6. Show me how to publish and subscribe to events using EventBus and
   RedisManager from the utilities exports.

Use only the exports documented in USAGE.md and visible in the source files.
Do not invent any API methods.

License and credit

The Conduit platform is released under the MIT License (see source/LICENSE). It is developed and maintained by Quintessential SFT. The upstream source is available at the conduit npm package and the ConduitPlatform/Conduit GitHub repository.

This product’s unique contribution is clean room implementation of valuable code block into AVCP compatible standard.

The full install guide and integration prompts unlock after purchase.
