Required dependencies

npm install @noble/ciphers @noble/hashes fontkit linebreak png-js

No native modules or build steps (pod install / Android linking / expo prebuild) are required. This library runs in Node.js and modern browsers. For browser builds, a bundler (webpack/esbuild/Vite) with a Buffer polyfill is needed.

Project setup

1. Copy the source/ directory into your project, e.g. src/pdfkit/.
2. Ensure your tsconfig.json (or jsconfig.json) includes the source root:

   {
     "compilerOptions": {
       "baseUrl": ".",
       "paths": {
         "pdfkit/*": ["src/pdfkit/*"]
       },
       "allowJs": true,
       "esModuleInterop": true
     }
   }


3. If using Babel, add @babel/plugin-transform-modules-commonjs or ensure "type": "module" is set in your package.json for ESM.
4. For Node.js streaming to a file, no additional env vars are required. For browser usage, configure your bundler to polyfill Buffer and stream.
5. Import PDFDocument from src/pdfkit/document.js as your entry point — all other modules are loaded transitively.

Public API

PDFDocument

import PDFDocument from './src/pdfkit/document.js';

const doc = new PDFDocument(options?: {
  size?: string | [number, number];   // e.g. 'A4', 'LETTER', or [width, height] in points
  margin?: number;
  margins?: { top: number; bottom: number; left: number; right: number };
  layout?: 'portrait' | 'landscape';
  info?: { Title?: string; Author?: string; Subject?: string; [key: string]: any };
  pdfVersion?: '1.3' | '1.4' | '1.5' | '1.6' | '1.7' | '1.7ext3';
  userPassword?: string;
  ownerPassword?: string;
  permissions?: object;
  autoFirstPage?: boolean;
  bufferPages?: boolean;
  lang?: string;
  displayTitle?: boolean;
  tagged?: boolean;
});

PDFDocument is the root object. Pipe its output stream to a writable (file, HTTP response, or blob) and call .end() to finalize. All drawing, text, font, and image methods are accessed through this object via mixins.

LineWrapper

import LineWrapper from './src/pdfkit/line_wrapper.js';

new LineWrapper(document: PDFDocument, options: {
  width: number;
  height?: number;
  columns?: number;
  columnGap?: number;
  indent?: number;
  indentAllLines?: boolean;
  ellipsis?: boolean | string;
  horizontalScaling?: number;
  characterSpacing?: number;
  wordSpacing?: number;
  features?: string[];
});

Used internally by the text mixin to handle automatic line wrapping, multi-column layout, and soft-hyphen processing. Use directly only when implementing custom text rendering logic outside the standard .text() mixin.

PDFTable (via table/index.js)

import PDFTable from './src/pdfkit/table/index.js';

new PDFTable(document: PDFDocument, opts?: {
  data?: Iterable<Iterable<TableCell>>;
  // ... table-level style/layout options
});

table.row(row: Iterable<TableCell>, lastRow?: boolean): this | PDFDocument;
table.end(): PDFDocument;

PDFTable renders a structured table into the document. Pass data for a single-call approach, or call .row() incrementally and finalize with .end(). Returns this for chaining unless lastRow is true.

Working examples

Scenario - Generate a PDF invoice to a file

Creates a single-page PDF with a title, line of text, and saves it to disk using Node.js streams.

import PDFDocument from './src/pdfkit/document.js';
import { createWriteStream } from 'fs';

const doc = new PDFDocument({
  size: 'A4',
  margin: 50,
  info: { Title: 'Invoice #1001', Author: 'Acme Corp' },
});

const stream = createWriteStream('invoice.pdf');
doc.pipe(stream);

doc
  .fontSize(25)
  .text('Invoice #1001', 50, 80)
  .moveDown()
  .fontSize(12)
  .text('Bill To: John Doe')
  .text('Amount Due: $250.00')
  .moveDown()
  .text('Thank you for your business.');

doc.end();

stream.on('finish', () => console.log('invoice.pdf written'));

Scenario - Embed a custom font and draw vector graphics

Loads an OTF font from disk, renders styled text, then draws a filled triangle using path operations.

import PDFDocument from './src/pdfkit/document.js';
import { createWriteStream } from 'fs';

const doc = new PDFDocument({ size: 'LETTER' });
doc.pipe(createWriteStream('graphics.pdf'));

// Embed font
doc
  .font('./fonts/Roboto-Bold.ttf')
  .fontSize(20)
  .text('Vector Graphics Demo', 100, 60);

// Draw filled triangle
doc
  .save()
  .moveTo(100, 150)
  .lineTo(100, 250)
  .lineTo(200, 250)
  .fill('#E63946');

// Draw SVG path
doc
  .restore()
  .scale(0.6)
  .translate(350, -250)
  .path('M 250,75 L 323,301 131,161 369,161 177,301 z')
  .fill('steelblue', 'even-odd');

doc.end();

Scenario - Render a table with multiple rows

Uses PDFTable to render a data table in a single call using the data option.

import PDFDocument from './src/pdfkit/document.js';
import PDFTable from './src/pdfkit/table/index.js';
import { createWriteStream } from 'fs';

const doc = new PDFDocument({ margin: 30 });
doc.pipe(createWriteStream('table.pdf'));

new PDFTable(doc, {
  data: [
    [{ value: 'Product', bold: true }, { value: 'Qty', bold: true }, { value: 'Price', bold: true }],
    [{ value: 'Widget A' }, { value: '3' }, { value: '$9.00' }],
    [{ value: 'Widget B' }, { value: '5' }, { value: '$25.00' }],
  ],
});

doc.end();

Scenario - Password-protect a PDF

Creates an encrypted PDF using AES (PDF 1.7) with user and owner passwords.

import PDFDocument from './src/pdfkit/document.js';
import { createWriteStream } from 'fs';

const doc = new PDFDocument({
  pdfVersion: '1.7',
  userPassword: 'open123',
  ownerPassword: 'admin456',
  permissions: {
    printing: 'highResolution',
    copying: false,
    modifying: false,
  },
});

doc.pipe(createWriteStream('secure.pdf'));
doc.fontSize(14).text('This document is encrypted.', 100, 100);
doc.end();

File walkthrough

• document.js — Instantiates and orchestrates the full PDF document; applies all mixins; manages pages and the output stream.
• page.js — Represents a single PDF page, its media box, content stream, and resource dictionaries.
• font.js / font_factory.js — Coordinate font loading (standard 14 or embedded), metrics resolution, and PDF font resource registration.
• image.js — Detects JPEG vs. PNG and delegates to the appropriate parser in image/.
• line_wrapper.js — Implements line-breaking via the linebreak package with column, indent, ellipsis, and soft-hyphen support.
• gradient.js — Builds PDF Function-based linear and radial gradient shading objects.
• pattern.js — Implements PDF tiling patterns for repeating fill textures.
• path.js — Parses SVG path d attribute strings and translates commands to PDF path operators.
• security.js — Handles PDF encryption setup (RC4 v2/4, AES v5), key generation (MD5/SHA-256), and permission flags.
• metadata.js — Serializes XMP metadata into a PDF stream for standards compliance.
• outline.js — Manages the PDF outline (bookmark) tree structure.
• object.js — Serializes JavaScript values to PDF syntax (dicts, arrays, strings, names).
• reference.js — Represents and serializes PDF indirect objects with their byte offsets.
• abstract_reference.js — Shared interface for direct and indirect reference types.
• name_tree.js / number_tree.js — PDF name and number tree builders for efficient lookup tables.
• tree.js — Generic balanced-tree helper used by name/number trees.
• data.js / binary.js — Low-level byte buffer and binary stream wrappers.
• utils.js — Numeric precision helper PDFNumber and miscellaneous utilities.
• virtual-fs.js — Filesystem abstraction layer allowing font/image loading in both Node.js and browser environments.
• spotcolor.js — Adds PDF Separation (spot) colorspace support.
• structure_element.js / structure_content.js / structure_annotation.js — Tagged PDF logical structure tree elements for accessibility.
• crypto/ — Self-contained implementations of AES-CBC/ECB, MD5, RC4, SHA-256, and CSPRNG (no Node.js crypto dependency required).
• font/afm.js — Parses Adobe Font Metrics for the 14 standard PDF fonts. font/embedded.js — Subsets and embeds TTF/OTF fonts via fontkit. font/standard.js — Resolves standard font names.
• image/jpeg.js / image/png.js — Extract image dimensions, color space, and raw data from JPEG and PNG buffers.
• mixins/ — Each file adds a capability group to PDFDocument: text.js (text drawing), vector.js (paths/shapes), color.js (fill/stroke), fonts.js (font selection), images.js (image embedding), annotations.js (links/notes), acroform.js (form fields), table.js (table API), outline.js (bookmarks), metadata.js (XMP), markings.js (marked content), pdfa.js/pdfua.js (standards compliance), attachments.js (file attachments), subsets.js (font subsetting), security.js-adjacent helpers.
• saslprep/ — Implements RFC 4013 SASLprep profile for normalizing PDF passwords before hashing.
• table/ — index.js exports PDFTable; normalize.js canonicalizes cell options; size.js measures columns/rows; render.js draws borders and content; style.js resolves inherited styles; accessibility.js adds table structure tags; utils.js provides table helpers.

Common pitfalls and fixes

• ESM vs. CJS interop: The source uses ES module import/export. If your project uses require(), add "type": "module" to package.json or transpile with Babel/esbuild; mixing syntaxes without a bundler will throw SyntaxError.
• Buffer not defined in browser: PDFKit relies on Node.js Buffer. Fix: add the buffer polyfill in your bundler config (e.g. resolve.fallback: { buffer: require.resolve('buffer/') } in webpack).
• fontkit peer resolution: fontkit must be installed separately (npm install fontkit); it is not bundled in this source and its absence causes silent failures when embedding non-standard fonts.
• Password normalization requires saslprep: The security.js module calls saslprep for password processing; if the saslprep/ directory is missing or excluded from your bundle, encrypted PDFs will fail to generate.
• png-js for indexed/transparent PNGs: Standard PNG parsing via png-js is required for indexed PNGs and PNGs with alpha channels; omitting it means only JPEG images will embed correctly.
• Large fonts and subsetting: When embedding large font files, font/embedded.js performs subsetting via fontkit. Ensure your bundler does not tree-shake fontkit's glyph layout internals, or subsetting will produce corrupt font streams.

Vibe-coding prompt template

I have dropped the PDFKit library source (pdfkit@0.18.0) into `src/pdfkit/` in my project.
The integration guide is in `USAGE.md`. Please help me integrate it step by step.

Context:
- Source root: src/pdfkit/
- Entry point: src/pdfkit/document.js (default export: PDFDocument)
- Table API: src/pdfkit/table/index.js (default export: PDFTable)
- Upstream package: user@example.com
- Runtime deps already installed: @noble/ciphers, @noble/hashes, fontkit, linebreak, png-js

Tasks:
1. Wire up PDFDocument so I can generate a PDF and pipe it to an Express response stream.
2. Add a route that accepts JSON invoice data and returns a downloadable PDF.
3. Embed a custom TTF font from the `fonts/` directory.
4. Render a data table using PDFTable with headers and row data from the request body.
5. Optionally add password protection using the pdfVersion and userPassword options.

Please read USAGE.md for real import paths, working code examples, and known pitfalls before writing any code.
Do not use the npm pdfkit package — import directly from src/pdfkit/document.js.

License and credit

PDFKit is released under the MIT License. See source/LICENSE if present, or refer to the upstream repository and the npm package page for the full license text and attribution. Credit: originally authored by Devon Govett and maintained by the Foliojs contributors.

This product’s unique contribution is clean room implementation of valuable code block into AVCP compatible standard.
